China Best Wholesale Photovoltaic 12V 24V 220V 1kw 1000 Watt 1500W 1000W 6kw 2kw 5000W 3000W DC to AC Power PV MPPT Hybrid Solar Panel Inverter Prices for Home

1 / 5

China Best Wholesale Photovoltaic 12V 24V 220V 1kw 1000 Watt 1500W 1000W 6kw 2kw 5000W 3000W DC to AC Power PV MPPT Hybrid Solar Panel Inverter Prices for Home

Customization:	Available
After-sales Service:	Yes
Warranty:	1~12 Months

Send Inquiry

Product Description

📊

Basic Information

Model NO.

XD-HP PRO T

Source Flow

Active Inverter

Phase

Single Phase

Output Power

1000W - 8000W

Certification

CE, ISO9001

Type

DC/AC Inverters

Wave String

Pure Sine Wave

Efficiency

>99%

Battery Type

Lithium/Lead Acid/Gel

Output Frequency

50/60Hz

💡

Inverter Features

01High frequency design, high power density, and small size with low no-load loss.

02Built-in MPPT solar charge controller for optimized solar energy utilization.

03Pure sine wave output, adaptable to all types of residential and industrial loads.

04Adjustable battery voltage parameters to suit different battery types and prolong life.

05Three working modes: AC first, Battery first, and PV first selectable by users.

06Comprehensive protection: Overload, over-temperature, and short circuit protection.

🌟

Main Highlights

🔍

Product Details

📋

Specifications

Technical Parameters
Basic Parameters
Model	10212	20224	50248
Rated Power	1000W	2000W	5000W
Battery Voltage	12VDC	24VDC	48VDC
PV Input (MPPT)
Charging Mode	MPPT
Max PV Input Voc	120VDC		500VDC
MPPT Voltage Range	15V-80VDC	30V-100VDC	120V-450VDC
AC Output
Output Voltage	220VAC / 230VAC / 240VAC ± 2%
Waveform	Pure Sine Wave
Transfer Time	≤ 10ms

🔌

Wiring Diagram

📦

Packing & Delivery

Package: Standard Carton Box for safe packaging; Wooden Boxes recommended for samples to ensure protection during transit.

Shipping Options:

Express: FedEx/DHL/TNT/UPS (Door-to-Door) for samples.
Freight: By Air or Sea for batch goods.
Delivery Time: 7 days for samples; 10-25 days for bulk orders.

🏭

Workshop & Facility

❓

Frequently Asked Questions

What is the output efficiency of this inverter?

The inverter features a high-efficiency design with a peak output efficiency of over 99% in AC mode and 94% in Battery/PV mode.

What battery types can I use with the XD-HP PRO T?

It is compatible with Lithium, Lead Acid, and Gel batteries. Charging and discharging parameters can be customized via the operation panel.

Does this inverter support remote monitoring?

Yes, it includes an optional RS485 communication port and supports WiFi or GPRS monitoring via a dedicated mobile APP.

What are the available working modes?

Users can choose between three adjustable modes: AC Priority, Battery Priority, or PV Priority, depending on their energy needs.

What is the transfer time between power sources?

The transfer time is less than or equal to 10ms, ensuring seamless power for sensitive electronic devices.

Can this inverter be used with a generator?

Yes, it features an extra-wide voltage and frequency input range that supports both mains power and generators.
