• Built-in UPS and black start capability
• 100% unbalanced output supported
• 110% continuous AC overloading
• Type II SPD integrated on DC and AC sides
• Multiple MPPTs input for optimized energy
• DC/AC Ratio up to 2.0
• Maximum efficiency up to 98%
• Scalable capacity up to 165kW
• Support for both lithium and lead-acid batteries
• Remote control compatibility for DG
| Datasheet | WIT 28K-HU-US L2 | WIT 35K-HU-US L2 | WIT 40K-HU-US L2 | WIT 55K-HU-US L2 |
|---|---|---|---|---|
| Input Data (PV) | ||||
| Max PV Power | 54kW | 75.6kW | 86.4kW | 108kW |
| Start Voltage | 195V | |||
| Max Input Voltage | 800V | |||
| No. of MPP Trackers | 5 | 7 | 8 | 10 |
| Output Data (AC) | ||||
| Nominal Power | 28kW | 35kW | 40kW | 55kW |
| Max Apparent Power | 30.8kVA | 38.5kVA | 44kVA | 60.5kVA |
| Nominal Voltage | 208V/220V, -15%~10% | |||
| Efficiency | Max 98.2% | |||
| General Data | ||||
| Protection Degree | IP66 / NEMA 4X | |||
| Cooling | Smart Air Cooling | |||
Providing total solutions based on clean sustainable solar energy. Our focus encompasses product development, production, and system integration. We aim to deliver reliable and cost-effective solar energy solutions globally, including solar panels, hybrid systems, inverters, and lithium-ion battery technology. Every product is backed by rigorous quality control and design excellence.
