When utility power is available, the inverter will transfer this power to the household appliances (load). When utility power is disconnected, the inverter will switch back to inverting from the batteries without disrupting the power going to the appliances.
When inverter output is available, output as inverting is priority. When inverter output is unavailable, this unit will transfer to utility, the utility supply AC to equipments.
| Parameter Specification | Details | ||||
|---|---|---|---|---|---|
| Continuous Power | 2500W | ||||
| Peak Power | 4900W | ||||
| DC Voltage | DC 12V / 24V | AC Voltage | 100V/110V/120V or 220V/230V/240V ± 3V | ||
| Efficiency | 12V: up to 89%; 24V: up to 91% | Transfer Time | Less than 30ms | ||
| THD | <3% (Linear load) | Frequency | 50HZ ± 0.5HZ or 60HZ ± 0.5HZ | ||
| Power-Saving | Activates when output < 5W; Returns to normal when > 10W. | ||||
| Ignition Function | Inverters start/shut down simultaneously with vehicle engine via starter connection. | ||||
| Protection Type | Code | Indicator / Action |
|---|---|---|
| Low Voltage Alarm | F05 | Buzzer sounds and fault light turns red |
| Low Voltage Shutdown | F01 | Manual recovery required (Auto recover if voltage stabilizes within 20ms) |
| Over Input Voltage | F02 | Inverter shutdown; Manual recovery required |
| Over Load Alarm | F06 | Triggered at ~110% load; Buzzer and Red light |
| Over Load Protection | F03 | Shutdown at ~120% load; Manual recovery |
| Over Temperature Alarm | F07 | Internal temp > 90±5ºC |
| Over Temperature Protection | F04 | Auto-recovery when temp drops to 80±5ºC |
| Short Circuit Protection | F03 | Recover by hand |
| AC Input Overload | F09 | Fan starts at 60±5ºC; Alarm/No output at 75±5ºC |
