Best Quality 1000W UPS Modified Sine Wave Inverter with 4 USB and 3 AC Optional Sockct

1 / 5

Best Quality 1000W UPS Modified Sine Wave Inverter with 4 USB and 3 AC Optional Sockct

Still deciding? Get samples of $ !

Order Sample

Send Inquiry

Product Description

1000W Off-grid Solar Power Inverter Modified Sine Wave with UPS and Charger

📊 LCD Display

Real-time status monitoring

🔌 3 AC Sockets

Multiple output support

📱 4 USB Ports

Independent Switch Control

🛡️ Full Protection

Smart security features

Basic Specifications

Model NO.

CXUPS-1000W

Output Power

501 - 1000W

Peak Load Power

2000W

Efficiency

> 90%

Frequency

50Hz / 60Hz

Certification

CE, RoHS

Circuit Topologies

Full-Bridge Type

Waveform

Square/Modified Sine Wave

Machine Size

220*160*105mm

Weight

2.5kg

Product Gallery

Product Features

This 1000W multi-function UPS power inverter is designed for high reliability and ease of use. It utilizes high-frequency pulse width modulation technology and a high-quality double-faced circuit board.

✔ Smart Cooling Fan: Runs at specific temperatures to prevent overheating.
✔ Comprehensive Protection: Includes overload, over-current, high-temperature, short-circuit, and battery reverse connection protection.
✔ Automated Alerts: Low battery alarm at 11V and automatic shutdown at 10.5V to protect battery lifespan.
✔ Environment Friendly: Operates with no noise, no fumes, and no fuel requirements.

Wide Application Range

🚗 Travel: Cars, ambulances, ships, traffic lights.

☀️ Energy: Solar energy, wind power systems.

💻 Office: Computers, printers, monitors, scanners.

🏠 Home: TV, fans, vacuum cleaners, DVD, audio.

🍳 Kitchen: Microwaves, refrigerators, electric pots.

🔧 Tools: Saws, drilling machines, air compressors.

Technical Parameters

Input Voltage Range	10.5-15V / 21-30V / 42-60V
Output Voltage	220V ± 10%
Output Frequency	50/60 Hz
Continuous Output Power	1000W
Peak Power	2000W
Conversion Efficiency	> 90%
No-load Consumption	< 1.5A
Output Waveform	Modified Sine Wave
Operating Temperature	< 65°C
Packaging Size	55.00cm * 40.00cm * 48.00cm

Frequently Asked Questions

What is the peak power of this 1000W inverter?

The inverter provides a maximum instant peak power of 2000W to handle initial surges from high-load equipment.

Does it support both 50Hz and 60Hz frequencies?

Yes, the device is designed to operate at either 50Hz or 60Hz, making it compatible with various regional standards.

How many devices can I charge via USB simultaneously?

The unit features 4 USB ports with an independent switch, allowing you to charge multiple mobile devices or electronics at once.

What happens if my battery voltage gets too low?

The inverter includes an alarm that sounds at 11V and will automatically shut down if the voltage drops below 10.5V to prevent permanent battery damage.

Is this inverter suitable for sensitive electronics like laptops?

Yes, the modified sine wave output is suitable for most office equipment including computers, printers, and digital cameras.

Does the cooling fan run constantly?

No, it features a smart cooling fan that only activates when a certain internal temperature is reached, ensuring quiet operation and energy efficiency.
